ProMinent delta General Operating Instructions

3 Installation, hydraulic
3.1 Overview and Information on Accessories
In addition to a correctly selected metering pump, individually combined
hydraulic and electrical accessories are needed for the perfect operation
of metering systems. A number of accessories are shown on the following
pages, which are not always needed but provide an overview of the pos‐
sible options. We would be happy to assist with the selection of the right
accessories for your metering tasks and are also available for ongoing
advice, for instance on pipe calculations.
pk_1_001_1_hydr
B
E
I
C
D
F
A
H
G
Fig. 2: Example of an installation with different accessories
Installation, hydraulic
8

ProMinent delta Specifications

General

Stroke rate	max. 180 strokes/min
Type	Diaphragm metering pump
Materials	PVDF, PTFE, stainless steel
Protection class	IP 65
Diaphragm material	PTFE
Drive	Solenoid
Power supply	230 V, 50/60 Hz
