4.2 Installation (hydraulic)
CAUTION!
Free outlet at sensor outlet
Feed the sample water which has
flowed through the sensor to a
free drain. The sampled water
may not be fed back into the
process.
CAUTION!
Algae growth under the influence
of light
Possible algae growth if unsuit‐
able hoses are used.
Do not use transparent hoses if
the installation is subjected to
powerful sources of light. This
prevents the formation of algae in
the installation.
Leakage on the bleed screw
Slight leakage may occur at the
bore hole for the bleed screw
during the installation process.
This will cease as soon as normal
flow is established.
In the event that the installation
continues to leak permanently at
this point due to the high pressure
in this area, we recommend
sealing off the bore hole with the
sealing plug supplied. In order to
ensure free drainage, a bleed
option must be installed at
another area of the outlet in order
to avoid overpressure or under‐
pressure in the system.
Permissible operating param‐
eters
–
Maximum liquid temperature
50 °C
–
Maximum pressure 13.8 bar
–
Flow rate 6 ... 60 l/h
Mounting and Installation
21
