Drying agent alarm
Fig. 21: Drying agent alarm
Function Options Info
Drying agent alarm
(DESC)
[ON]
(On)
[OFF]
(Off)
Factory setting:
[OFF]
Select
[ON,]
in order to
trigger an alarm when
the drying agent is satu‐
rated
In order to activate one or both alarms, then you must configure
„ERROR“
, see
Ä Chapter 6.4.3 „Configure alarm “ on page 38
.
In order to indicate an error via the 4-20 mA signal,
„ERROR ALARM (ERLV)“
must be selected in alarm current, see
Ä Chapter 6.4.3 „Configure alarm
“ on page 38
.
Configuration of 4 mA output
Allow a constant output of 4 mA and will allow you to calibrate or adjust the 4
mA signal.
Commissioning
51
