Tab. 3: General assignment for further measuring/control units
Function Sensor ICT5 lead colours
Transmission coil, signal
[bn]
, brown
Transmission coil, signal, earth
[wh]
, white
Receiver coil, signal
[pk]
, pink
Receiver coil, signal, earth Cable shield for X2.1, transparent
Earth Complete cable shield, black
Pt100x
[gn]
green
Pt100x
[ye]
yellow
Connect the data line to the terminals of your measuring/control unit. Refer to the operating
instructions for your measuring/control unit
Assembly and installation
25
