4.3 Electrical installation
Do not shorten or mechanically damage the connecting cable.
Once connected, calibrate the inductive conductivity and temperature sensor.
Tab. 2: Terminal assignment, Dulcometer Compact
Terminal Function Sensor ICT5 lead colours
X1.1 Transmission coil, signal
[bn]
, brown
X1.2 Transmission coil, signal, earth
[wh]
, white
X2.1 Receiver coil, signal
[pk]
, pink
X2.2 Receiver coil, signal, earth Cable shield for X2.1, transparent
XE2.2 Earth Complete cable shield, black
XE4.1 Pt100x
[gn]
green
XE4 Pt100x
[ye]
yellow
The descriptions of the terminals refer to the ProMinent measuring and control unit, type DCCa. The
information about the colours relates to the leads of the sensor’s fixed data line.
Connect the data line to the terminals of your ProMinent measuring and control unit, type DCCa. In
doing so, refer to the relevant operating instructions
Connect the data line to the terminals of your measuring/control unit. Refer to the operating
instructions for your measuring/control unit
Assembly and installation
24
