2.2.2 Stroke movement
Set stroke length dependent on the required delivery capacity.
Product description S2Ba/S2Ca
5
6
3
7
1
8
4
10
Fig. 2
61_01-101_00_25-01
NOTE
A large stroke length and low metering frequency should be selected for very viscous
media!
A shorter stroke length and high frequency should be selected to achieve good mixing
properties!
20 0
0
50
25
75
5
75%
0
5
0
25
10
30%
Fig. 4
75 %
30 %
Fig. 3
+ Delivery stroke
b) At reduced stroke length
– Intake stroke
a) Stroke progression
at max. stroke rate
and stroke length
Stroke speed
Angle reduced stroke length
