Identcode ordering system
ProMinent
®
Identcode ordering system
Please enter the identcode on the device label into the grey box below.
S2Ba Sigma Basic Type (S2Ba)
HM Main drive, diaphragm
Pump type: (figures 1+2 = back pressure [bar], figures 3-5 = feed rate [l/h])
16050
16 bar; 50 l/h
16090
16 bar; 90 l/h
16130
16 bar; 130 l/h
12050*
10 bar; 48 l/h
12090*
10 bar; 86 l/h
12030*
10 bar; 125 l/h
07120
7 bar; 120 l/h
07220
7 bar; 220 l/h
04350
4 bar; 350 l/h * for SST versions, max. 12 bar
Liquid end materials:
PV PVDF
SS Stainless steel
Seal material:
T PTFE seal
Diaphragm:
0 Standard diaphragm, PTFE version
1 Double diaphragm with diaphragm rupture indicator (retro fit possible)
Liquid end version:
0 No spring
1 With 2 valve springs, Hastelloy C, 0.1 bar
4 With pressure relief valve, Viton
®
seal, no valve spring
5 With pressure relief valve, Viton
®
seal, and valve spring
Hydraulic connection:
0 Standard threaded connector (according to technical data)
1 Union nut and PVC insert
2 Union nut and PP insert
3 Union nut and PVDF insert
4 Union nut and stainless steel insert
7 Union nut and PVDF hose nozzle
8 Union nut and stainless steel hose nozzle
Version:
0 With ProMinent
®
logo (standard)
1 Without ProMinent
®
logo
Electrical power supply:
S3 ph, 230 V/400 V 50/60 Hz, 0.18 kW
M1 ph, AC, 230 V/50/60 Hz, 0.18 kW
N1 ph, AC 115 V 60 Hz, 0.18 kW
L3 ph, 230 V/400 V, 50 Hz, (EExe, EExde)
P3 ph, 230 V/400 V, 60 Hz, (EExe, EExde)
R3 ph, variable speed motor, 230/400 V, 0.37 kW
VVariable speed motor with integrated speed control 1 pH,
230 V, 50/60 Hz
Z1 ph, variable speed control set 1 ph, 230 V, 50/60 Hz
1 No motor, with B14 flange (Gr. 71 (DIN))
2 No motor, C 56 flange (NEMA)
3 No motor, B5 Gr. 63 (DIN)
4 No motor, B5, Gr. 70 (DIN)
Motor version:
0 IP 55 (standard)
1 Exe version (II 2G EExe II T3)
2 Exde version (II 2G EExde IIC T4)
AATEX type drive
Stroke sensor:
0 No stroke sensor (standard)
1 with stroke sensor (Hall sensor, no connection cable)
2 Pacing relay (reed relay)
3 Stroke sensor (Namur) intrinsically safe
Stroke length adjustment:
0 Manual (standard)
1 With stroke positioning motor, 230 V/50/60 Hz
2 With stroke positioning motor, 115 V/50/60 Hz
3 With stroke control motor,
0...20 mA 230 V/50/60 Hz
4 With stroke control motor
4...20 mA 230 V/50/60 Hz
5 With stroke control motor
0...20 mA 115 V/50/60 Hz
6 With stroke control motor
4...20 mA 115 V/50/60 Hz
S2Ba ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___
