ProMinent S2Ba - Dimensions Sigma; Dimensions Sigma; 2 with Stroke Adjustment Motor

Dulcodes UV-Desinfektionsanlage
Page 27
ProMinent
®
PVDF
PP/PVC/PTFE
SS
Connection
variations
3.1.3 Dimension sheet Sigma/ 2 with stroke adjustment motor
Anschluss-
varianten
Fig. 10
61_01-101_00_39-73_2_HM
Fig. 9
61_01-101_00_32-73
3.1.2 Dimensions Sigma/ 2 (mm)
* Dimensions for S2Ba
Technical data
18
100
186
78
218
Ø165
ØG
136
120
A
B
F
E/El
222
D/Dl 120
28
185/170*
Ø 6.5
+7
26.5
456/441*
C
79.5
Model Connector A B C D D1** E E1** F Q G
FM 130 PVT DN 15 265/250* 160 G 1 A 104 124 326/329* 346/349* 82 101
FM 130 SST DN 15 265/250* 160 G 1 A 104 124 326/329* 346/349* 82 101
FM 350 PVT DN 25 304/289* 237 G 1 1/2 A 115 135 337/340* 357/360* 84 148
FM 350 SST DN 25 304/289* 237 G 1 1/2 A 115 135 337/340* 357/360* 84 148
FM 130 = Identcode type 16050,16090,16130 FM 350 = Identcode type 04350,07120,07220
* Dimensions for S2Ba
** Dimensions with diaphragm rupture sensor
