Operating-/Settings Diagram
Continuous
display
Start/stop pump
Change directly alterable values
= Lock (CODE 1)
= Lock (CODE 2)
Prime
Start batch (in"batch" operating mode only)
Cancel error
Check adjustable values
2
1
p. 45
p. 52
p. 44
p. 51
next page
Select the operating mode here first,
then carry out the settings in the SET menu.
Exceptions: Timer and PROFIBUS
®
.
