* at rated load
The contacts are potential-free.
The pacing relay is a N/O as standard.
Supply voltage for pacing relay PCB
Available supply vol‐
tages
Mains supply fre‐
quency
Power consumption
230 V AC (180-254 V) 50 / 60 Hz 10 mA (at 230 V, 50 Hz)
115 V AC (90-134 V) 50 / 60 Hz 15 mA (at 115 V, 60 Hz)
24 V DC (20-28 V) - 10 mA (at 24 V DC)
Install the heating cartridge according to its documentation. It must
only be connected to the supplied power supply!
Install the other units in line with their documentation.
Heating cartridge
Other units
Installation, electrical
