14 Technical data
WARNING!
Risk of personal injuries
Please observe the ”Supplement for modified version“ at the
end of the chapter!
It replaces and supplements the technical data!
14.1 Performance data
Type Minimum pump capacity at maximum
back pressure
Maximum
stroke rate
Suction lift Permissible
priming pres‐
sure, suction
side
Connector
size
bar l/h ml/stroke Strokes/min m WS bar R"-DN
120145 PVT 10 146 33.7 72 5 2 1 1/2" -
DN25
120145 SST 12 146 33.7 72 5 2 1 1/2" -
DN25
120190 PVT 10 208 33.7 103 5 2 1 1/2" -
DN25
120190 SST 12 208 33.7 103 5 2 1 1/2" -
DN25
120270 PVT 10 292 33.8 144 5 2 1 1/2" -
DN25
120270 SST 12 292 33.8 144 5 2 1 1/2" -
DN25
120330 PVT 10 365 33.8 180 5 2 1 1/2" -
DN25
120330 SST 12 365 33.8 180 5 2 1 1/2" -
DN25
070410 PVT,
PPT, PCT
7 410 95.1 72 4 1 2" - DN32
070410 SST 7 410 95.1 72 4 1 2" - DN32
070580 PVT,
PPT, PCT
7 580 95.1 103 4 1 2" - DN32
070580 SST 7 580 95.1 103 4 1 2" - DN32
040830 PVT,
PPT, PCT
4 830 95.1 144 3 1 2" - DN32
040830 SST 4 830 95.1 144 3 1 2" - DN32
041030 PVT,
PPT, PCT
4 1030 95.1 180 3 1 2" - DN32
041030 SST 4 1030 95.1 180 3 1 2" - DN32
All figures refer to water at 20 °C.
The suction lift applies to filled suction line and filled liquid end - when
installed correctly.
Only for "M - modified" design:
S3Ba under 50 Hz operation
Technical data
45
