18 Wear parts for Sigma/ 3
18.1 Standard
Spare parts kit Types 070410, 070580,
040830, 041030
FM 1000 1034681
Scope of supply: see exploded view drawings.
Spare parts kit Types 120145, 120190,
120270, 120330
FM 330 1034678
Scope of supply: see exploded view drawings.
Spare parts kit Types 120145,
120190, 120270,
120330
Types 070410,
070580, 040830,
041030
FM 330 1034679
FM 330 with 2 complete valves 1034680
FM 1000 1034682
FM 1000 with 2 complete valves 1034683
Scope of supply: see exploded view drawings.
Spare parts kit for material ver‐
sion
Seals Part no.
SPK PRV 4 bar PVT/SST PTFE 1031204
SPK PRV 7 bar PVT/SST PTFE 1031205
SPK PRV 10
bar
PVT PTFE 1031201
Scope of supply: see exploded view drawings.
18.2 Physiological safety
Scope of supply with PVT material version
1 x Diaphragm, 2 x Valve balls, 1 x Suction valve, complete, 1 x Discharge valve, complete
1 x Elastomer sealing set (EPDM)
2 x Ball seat housings, 2 x Ball seat discs, 4 x Composite seals
1x Seal washer (for bleed valve or relief valve)
Spare parts kits PVT, PCT, PPT (liquid
ends)
Spare parts kits PVT (liquid ends)
Spare parts kits SST (liquid ends)
Spare parts kits for integrated relief valve
Spare parts kits
Wear parts for Sigma/ 3
