Fig. 31: Sigma/ 3 SST relief valve-A
Item Description Type 120145,
120190,
120270,
120330
Type 070410,
070580
Type 040830,
041030
10 Relief valve, compl. 12 bar SSA 1005625
10 Relief valve, compl. 7 bar SSA 1005042
10 Relief valve, compl. 4 bar SSA 1005038
* The items listed are included in the spare parts kit. Springs made from Hastelloy C, O-rings from FPM-A and EPDM.
Technical changes reserved.
Sigma/ 3 SST relief valve-A
Exploded drawings Sigma/ 3
