Promise Technology Vess A Series Quick Start Guide

AVAiLABLe Pci/PMc hArDwAre coMBinAtions
There are 25 different PCI/PMC hardware combinations available for
installation in the Vess A6120. The columns in the table below list the location
of the four slots in the table header, with the type of card installed, if any, listed
in each column. Note that the table is split across this page and the next page.
Note that the location descriptions, Lower Left, Upper Left, Lower Right and
Upper Right refer to the PCI/PMC slot locations as viewed from the rear of the
device.
Lower Left Upper Left Lower Right Upper Right
1 none none none G
2 none E none G
3 none F none G
4 none G none none
5 none G none E
6 none G none F
7 none G D none
8 A none none none
9 A none none E
10 A none none F
11 A none D none
12 A E none none
13 A E none F
14 A E D none
A. Two port 1G BASE-T
B. Two port 10G BASE-T
C. Two port 10G SFP+
D. SAS Expansion
E. Extension RAID Board
F. Graphic Card
G. Four port 1G BASE-T
27
Vess A6120 Storage Server Appliance
