The rear panel of the Vess A6120 provides a network port for system
administration. This is also where the VGA video port is located, USB 3.0
ports, and the power insert for the power connection.
Other features depend on what PCIe card, or combination of PCIe cards are
installed. Please see the Product Manual for a complete list of the supported
PCIe hardware options.
The types of ports and connections available on the Vess A6120 include:
• Two port 10G BASE-T
• Two port 10G SFP+
• Two port 1G BASE-T
• Four port 1G BASE-T
• SAS HBA (SFF-8644)
• M.2 RAID card
For a complete list of the available port options, please see the Product
Manual. For a brief overview of PCIe and PMC hardware options, see “PCI/
PMC add-on hardware” on page 26.
Vess A6120 rear view
VGA port
1000BASE-T
IPMI port
1000BASE-T
2 port NIC
Power inserts
USB ports
four USB 3.0 ports
PCI slots
RS-232
Serial port
