AN-X4-AB-DHRIO (DH+) Page 15
Keyword Possible Values
IP Factory
DHCP
static IP address, e.g., 192.168.1.187
Netmask Ethernet netmask, used only if IP is a static IP address
DefGtwy default gateway, used only if IP is a static IP address
Hostname Ethernet host name, from 1 to 30 characters
If you edit the file and AN-X finds an error in the file contents during startup, it flashes an error code
on the MS LED, see page 50.
Example IPCfg\IPConfig.txt files
Example: Factory default
IP: Factory
Hostname: ANX4
Example: DHCP
IP: DHCP
Hostname: ANX4
Example: Static IP address
IP: 192.168.1.14
NetMask: 255.255.255.0
DefGtwy: 192.168.1.1
HostName: ANX4
Firmware to Run
In addition to the Ethernet configuration, you will also need to edit the file
Firmware\FirmwareCfg.txt to select the firmware file to run. The contents of the file must exactly
match the name of one of the fimware files on the AN-X or the AN-X will not start up.
Example:
AN-X4-AB-DHP.v4.12.52.qtf
