Page 48 AN-X4-AB-DHRIO (DH+) Nov 2022
Hostname
Enter a Hostname for the AN-X4. This name is used internally by AN-X and may be used to
identify the AN-X if you have a DNS server on your network. The name can be from 1 to 30
characters long. The default hostname is ANXxxxxxx, where xxxxxx is the serial number of the
AN-X module.
AN-X Firmware Select
Use Administration/AN-X Firmware Select to select a firmware (*.qtf) file the AN-X is to run
from the list. AN-X builds the list from the firmware files on the microSD card that are
compatible with the AN-X hardware.
Click SUBMIT to run the firmware you have selected. You must REBOOT the AN-X to run the
firmware you selected.
AN-X Firmware Upload
Use Administration/AN-X Firmware Upload to upload a firmware (*.qtf) file to the AN-X.
Uploading a qtf file automatically selects the file. You must REBOOT the AN-X to run the
firmware you uploaded.
AN-X Firmware Remove
Use Administration/AN-X Firmware Remove to remove a firmware (*.qtf) file from the AN-X.
You cannot remove the file that is currently running on the AN-X.
AN-X Archive
Use Administration/AN-X Archive to create an archive that contains the current AN-X
configuration and logs, for use by technical support.
Click the CREATE ARCHIVE button to create the archive file. There is a slight delay while
AN-X builds the archive file.
Once AN-X has built the archive file it displays a second web page. Click the Download Archive
File button to save the file to your computer.
AN-X Kernel Page
Use Administration.AN-X Kernel Page to display the version of the Linux kernel on the AN-X.
