AN-X4-AB-DHRIO (DH+) Page 33
Example 7
127 Eth 192.168.1.65 Slot 2 DHB
This routing definition uses link ID 127.
It shows how to route messages across Ethernet to a 1756-ENBT at IP address 192.168.1.65,
across the backplane to a 1756-DHRIO in slot 2, and then to another Data Highway Plus network
connected to channel B on the 1756-DHRIO.
You must use RSLinx to configure the 1756-DHRIO routing table with a return path to the
originating AN-X at IP address 192.168.1.12 and local Link ID 121.
Right click on the 1756-DHRIO module and select Module Configuration, then select the Routing
Table tab.
Sample AN-X Router Configuration File
; AN-X-DHP Routing Table
LocalLinkID 121
0 Eth 192.168.1.65 Slot 1 CLX
1 Eth 192.168.1.65 Slot 1 CLX
122 Eth 192.168.1.14 Slot 1 DHA
132 PlcCsp 101.122.166.15
142 Eth 101.101.122.166 Slot 1 DHA
