Page 4 AN-X4-AB-DHRIO (DH+) Nov 2022
Multiple Programmer Access 22
USING DDE/OPC AND UNSCHEDULED MESSAGES 23
DDE/OPC 23
Sending Unscheduled Messages 23
Message Queues 26
USING DHP-HMI IP ALIASING 27
Overview 27
Ethernet/IP on Aliased Addresses 27
Alias Configuration File 28
Configure Aliases 28
Accessing Data 29
Example: PanelView RSLinx Enterprise 29
Example: RSLinx 29
ROUTING MESSAGES FROM DATA HIGHWAY PLUS 30
Local LinkID 30
Routing Definitions 30
Examples: 31
Sample AN-X Router Configuration File 33
Configuring the Router Function on the AN-X 34
Viewing the Current Router Configuration 34
Sending Remote Messages Using AN-X Routing 35
USING THE WEB INTERFACE 39
Data Highway Plus Configuration 39
Monitor Diagnostic Counters 41
Configure DH+ HMI IP Aliasing 42
View IP Alias File 42
Configure DH+ Router 43
