AN-X4-AB-DHRIO (DH+) Page 51
Data Highway Plus Operation
MS LED Meaning
YELLOW/9 DH+ Failed to start
RED/4 Router Server exited
RED/5 Ethernet/IP Server exited
RED/6 RED/6 Ethernet CSP Server exited
GREEN No Ethernet Comm errors
RED/blink Ethernet Comm Error - Check logs
NS LED Meaning
GREEN No DH+ errors
RED/blink DH+ Comm Error - Check Diag Counters
YELLOW DH+ - No other nodes
RED DH+ Excessive errors
RED/YELLOW
alternating
Duplicate station
