Digital Video Recorder
12
Connect to monitor and output video signals.
5. UTP network port
Connect to Ethernet devices, e.g. Ethernet switch, Ethernet hub, etc.
6. Power supply
Connect to DC12V/3A power supply.
7~9. Connection terminal of alarm input/output signal and RS485 signal
Connect to peripheral equipment like alarm, decoder, pan/tilt, etc.
10. Fan
It is used to keep ventilation in side the case. It cannot be blocked by any articles.
