10
3RD 4TH
7 Desired Set Temperature
Indicates desired room temperature(s). Also displays the highest and lowest temperatures
for the day.
8 Wi-Fi icons
One dot indicates the thermostat recognizes the wireless module. The “full” icon indicates the
thermostat is currently connected to the Local access point, via the optional Wi-Fi Module.
9 Setup Step icon
Indicates the step number when the thermostat is in the setup mode.
10 2nd, 3rd and 4th Stage icons
Indicates what stage of cooling or heating is currently energized.
11
icon
Indicates the keypad has been locked.
7
7
8
10
10
11
9
Display
Features
