7 User Manual
1 Ambient Light Sensor
2 Backlit, Scrolling LCD Display
3 OVERRIDE Button
4 Warmer & Cooler Buttons
5 Heat or Cool Indicator
Heat = Red, Cool = Green
6 Setup Buttons behind door
1 About Your Thermostat
Table for button presses
that are required for
entering various menus
1
2
3
4
5 6
Front Display
TO ENTER MENUS BUTTON PRESS
Setup Steps Press SETUP button
Time Schedule Press SET CLOCK button
Emergency Heat Press EMERGCY HEAT button
Lockout Buttons MODE, Up & Down for 2 seconds
Calibration Press SETUP for 10 seconds
Wireless Setup Press ACCESSRY SETUP button
PSP4272C User Manual.indd 7PSP4272C User Manual.indd 7 6/9/21 11:05 AM6/9/21 11:05 AM
