17 User Manual
Installer
Setup Steps
(see Installer Manual
for more details)
Step# Description Pg# Range FD
Installer
Setup Steps
(see Installer Manual
for more details)
53 Reheat Operation W/Cool To Dehum. On, Off Off
54 Fan Off Delay 0 - 120 Seconds 0
55 F/C Fahrenheit (F), Celsius (C) F
56 Aux Output Polarity Open, Closed Open
57 Aux Output Time, Temperature,
External, Economizer Time
58 Aux Output Program Days 1 Day, 5/1/1 Day, 7 Day 1
59 Day Of Week To Program Sunday - Monday (S - M) MTWTFSS
60 Aux Output Start Time 12am - 12am 7am
61 Aux Output Stop Time 12am - 12am 9pm
62 Copy Yes, No No
63 Aux Output Temp Source Tstat, Outdoor, Remote, External Remote
64 Aux Output Trigger Point Temp 0 - 120 Degrees 65
65 Comfort Recovery On, Off Off
66 Dry Contact Polarity Open, Closed Open
67 Dry Contact Use Cond. Pan, Occ., FDD, Holiday, Doorswitch Occupied
68 Humidity Polarity Open, Closed Open
69 Dehumidify Polarity Open, Closed Open
70 Dehumidify only with Cooling On, Off On
71 Light Activation Sensitivity Press Fan button to set current light level
72 Light Activation to Occupied On/Off Off
73 ProStat+ Skyport On, Off On
74 Local API On, Off Off
75 ADR On, Off On
76 ADR Action Observe Setpoint Offset, Observe Observe Set-
Static Setpoints points Offsets
77 Event Max Cool Setpoint 65 - 99 90
78 Event Min Heat Setpoint 50 - 99 50
79 Static Cool Setpoint 65 - 99 82
80 Static Heat Setpoint 35 - 99 60
81 Cool Setpoint Offset 1 to 10 4
82 Heat Setpoint Offset -1 to -10 -4
83 Press Fan To Clear All Messages
PSP4272C User Manual.indd 17PSP4272C User Manual.indd 17 6/9/21 11:05 AM6/9/21 11:05 AM
