3 Technical Data and Structure
3.1 Conveyor / station designation key
Conveyor / station designation key
FG
2
0
4.
1/
2
1
C
FG = Conveyor / station
Product
ZF = Central filter
FGG = Conveyors for gravimetric dosing unit
(without floor flap)
FG3- = Conveyor installed from ∅315 to ∅200
FG 2K = 2-component conveyor/station
2 = 200 (∅ conveyed goods container 200 mm)
Size
0 = Conveyor with blower, central filter installed
Unit type
2 = Conveyor station with filter cartridge cleaning with
circulating air with microcontroller control system for
separate fan station
4 = Conveying station
1 = Cloth filter without cleaning
Filter type
3 = Filter plate
4 = Cloth filter with cleaning (compressed air)
5 = Filter element 0.2 m
2
with cleaning (circulating or
compressed air)
6 = Filter element 1.5 m
2
with cleaning (circulating or
compressed air)
0 = For separately installed blower station
Blowers
1 = Installed blower (50/60 Hz) 0.8 kW
Material conveyed goods container
1 = PA, low / FGG
2 = PA, high
3 = VA, FGG
4 = VA, high
5 = VA, FGG HG2
6 = VA high HG
0 = Without controls / connection box / terminal box
Electrical design
1 = Microcontroller control system
5 = Terminal box
6 = Plug connection:
A = Murr plug connection- (custom)
B = M12-Y plug connection- (custom)
Plug connection system - design
C = Phönix plug connection
HM = Solenoid
HZ = Lift cylinder
HG2 = Hot granulate max. 150° C
(Normal temperature max. 80°C)
