Model #s: PT 45-KFA, PT 70T-KFA,
PT 125T-KFA, PT 175T-KFA, PT 215T-KFA
CONSUMER: Retain this manual for future reference.
Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19076 USA
Phone: 215-891-8460 Fax: 215-891-8461 Web: www.pinacleint.com Email: info@pinnacleint.com
Owner’s Manual and
Operating Instructions
Kerosene
Forced Air Heaters
IMPORTANT: Read and understand all of the directions in this manual before assembling,
starting, or servicing the heater. Improper use of this heater can cause serious injury. Keep this
manual for future reference.
GENERAL HAZARD WARNING:
Be sure to comply with the instructions and warnings provided with this heater, or death, seri-
ous bodily injury and property loss, damage from the hazards of fire, explosion, burn, asphyxia-
tion, and carbon monoxide poisoning can result.
Only persons who can follow and understand these instructions should use or service this
heater. If you need heater information such as an instruction manual, labels, etcetera, contact
the manufacturer.
D
E
S
I
G
N
C
E
R
T
I
F
I
E
D
C US
