Protemp PT 45-KFA - User Manual

Protemp PT 45-KFA

16 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

Model #s: PT 45-KFA, PT 70T-KFA,

PT 125T-KFA, PT 175T-KFA, PT 215T-KFA

CONSUMER: Retain this manual for future reference.

Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19076 USA

Phone: 215-891-8460 Fax: 215-891-8461 Web: www.pinacleint.com Email: info@pinnacleint.com

Owner’s Manual and

Operating Instructions

Kerosene

Forced Air Heaters

IMPORTANT: Read and understand all of the directions in this manual before assembling,

starting, or servicing the heater. Improper use of this heater can cause serious injury. Keep this

manual for future reference.

GENERAL HAZARD WARNING:

Be sure to comply with the instructions and warnings provided with this heater, or death, seri-

ous bodily injury and property loss, damage from the hazards of fire, explosion, burn, asphyxia-

tion, and carbon monoxide poisoning can result.

Only persons who can follow and understand these instructions should use or service this

heater. If you need heater information such as an instruction manual, labels, etcetera, contact

the manufacturer.

D

E

S

I

G

N

C

E

R

T

I

F

I

E

D

C US
