Table of Contents
Features ................................................................ 3,4
Specifications ........................................................... 5
Safety Information .................................................... 6
Theory of Operation ................................................. 6
Unpacking and Assembly .......................................7,8
Fuels ........................................................................ 9
Ventilation ................................................................ 9
Operation ................................................................. 9
Maintenance ...................................................... 10,11
Storage ................................................................... 11
Troubleshooting .......................................................12
Wiring Diagrams ..................................................... 13
Replacement Parts
Exploded Parts Drawing ................... 14 & 16
Replacement Part Listing ........................15, 17 & 18
Warranty ....................................................Back Page
Features
WARNING:
Fire, burn, inhalation, and explosion hazard.
Keep combustibles, such as building materials,
paper or cardboard, a safe distance away from
the heater as recommended by these instruc-
tions. Never use the heater in spaces which
contain products such as gasoline, solvents,
paint thinners, dust particles, volatile or airborne
combustibles, or any unknown chemicals.
California Residents: Combustion by-products
produced when using this product contain car-
bon monoxide, a chemical known to the state of
California to cause cancer and birth defects (or
other reproductive harm).
Kerosene
Forced Air Heaters
WARNING:
Do not operate this heater until you have read,
and thoroughly understand these safety and
operating instruction. Failure to comply with the
precautions and instructions provided with this
heater can result in death, serious bodily injury,
property loss or damage from the hazards of
fire, explosion, burns, asphyxiation or carbon
monoxide poisoning. Only persons who can
read and understand these instructions should
use or service this heater.
Not for use in homes or recreational vehicles.
Page 2 Pinnacle Products International, Inc. Kerosene Owners Manual
Hot Air Outlet
Upper Shell
Lower Shell
Fuel Tank
Fan Guard
Pressure gauge
Fuel Gauge
Fuel Cap
Side Cover
Thermostat Knob
(3VE49A only)
Lamp
Power Cord
Power/Reset Switch
Handle
Extension
Cord Wrap
Electric Outlet
(120V 5amp max
non fused)
WARNING:
This is an unvented portable heater. It uses air
(oxygen) from the area in which it is used.
Adequate combustion and ventilation air must
be provided. Refer to VENTILATION Page 9.
Figure 1. Features of Models PT
45/70T
-KFA
Massachusetts Residents: Massachusetts
state law prohibits the use of this heater in any
building which is used in whole or in part for
human habitation. Use of this heating device in
Massachusetts requires local fire department
permit (M.E.L.C. 148, Section 10A).
New York City Residents: For use only at con-
struction sites in accordance with applicable
NYCFD codes. For approval numbers contact
the manufacturer 800-641-6996.
Never leave heater
unattended while burning,
or while connected to a
power source
