© 2012, Pinnacle Products International, Inc.
9
Propane Forced Air User’s Manual
Parts Breakdown
1 Outer Shell 22-524-0020 22-524-0021 22-524-0022 22-524-0022 1
2 Inner Shell Assembly 22-524-0004 22-524-0004 22-524-0005 22-524-0005 1
3 Base 22-501-0003 22-501-0001 22-501-0002 22-501-0002 1
4 Height Controller 22-512-0005 22-512-0005 22-512-0008 22-512-0008 1
5 Base Cover 22-508-0003 22-508-0001 22-508-0002 22-508-0002 1
6 Inner Shell Cap 22-505-0006 22-505-0010 22-505-0011 22-505-0008 1
7 Multi Bracket Assembly 22-504-0002 22-504-0002 22-504-0003 22-504-0003 1
8 Thermal Switch 22-603-0001 22-603-0010 22-603-0001 22-603-0001 1
9 Tubing Assembly 22-605-0001 22-605-0001 22-605-0002 22-605-0003 1
10 Nozzle 22-081-0007 22-081-0014 22-081-0015 22-081-0004 1
11 Nozzle Nut 22-518-0001 22-518-0001 22-518-0001 22-518-0002 1
12 Handle 22-511-0004 22-511-0005 22-511-0005 22-511-0005 1
13 Flange Hex Nut 22-518-0003 22-518-0003 22-518-0003 22-518-0003 1
14 Fan 22-514-0001 22-514-0001 22-514-0002 22-514-0002 1
15 Cushion Pad 22-509-0001 22-509-0001 22-509-0001 22-509-0001 1
16 Motor Assembly 22-061-0015 22-061-0015 22-061-0016 22-061-0016 1
17 Guard 22-101-0003 22-101-0003 22-101-0004 22-101-0004 1
18 Round Bolt 22-503-0002 22-503-0002 22-503-0003 22-503-0003 1
19 Valve Assembly 22-011-0005 22-011-0017 22-011-0018 22-011-0008 1
20 Inlet Connector 22-507-0003 22-507-0003 22-507-0003 22-507-0003 1
21 Spark Module – 22-604-0005 22-604-0005 22-604-0005 1
22 PCB Assembly 22-521-0001 22-521-0002 22-521-0002 22-521-0002 1
23 PCB Case 22-506-0001 22-506-0001 22-506-0001 22-506-0001 1
24 Valve Knob 22-516-0001 22-516-0001 22-516-0001 22-516-0001 1
25 Power Cord Assembly 22-131-0001 22-131-0001 22-131-0001 22-131-0001 1
26 Thermal Switch Cable 22-601-0001 22-601-0001 22-601-0001 22-601-0001 1
27 Hex Nut 22-518-0004 22-518-0004 22-518-0004 22-518-0004 1
28 Regulator Assembly 22-041-0004 22-041-0004 22-041-0005 22-041-0005 1
Reference Part Number for Models:
Number Description PT-40-GFA-A PT-60V-GFA PT-125V-GFA PT-150V-GFA-A Quantity
NEVER LEAVE HEATER UNATTENDED
WHILE BURNING, CONNECTED TO A
POWER SOURCE, OR WHILE
CONNECTED TO A FUEL SOURCE
