Protimeter Surveymaster User Manual

Page 12 Protimeter Surveymaster
Battery Low Indication:
Whenever the battery is low, there will appear a battery low
indication symbol on the screen (bottom right). This indicates
that the battery is low and should be replaced soon. The unit will
continue to perform in battery condition within the specified
accuracy, and turns off when the battery reaches the limit.
Holding / Freezing the Reading:
While measuring, if the reading needs to be frozen for any
observation, press during measurement. A text "HOLD"
will be displayed on the screen.

Protimeter Surveymaster Specifications

General

Display	Digital LCD
Power Supply	9V Battery
Operating Temperature Range	0°C to 50°C (32°F to 122°F)
Measurement Principle	Electrical Resistance, Radio Frequency
Non-Invasive Measurement Depth	Up to 19mm (3/4 inch)
Dimensions	190 mm x 70 mm x 49 mm (7.5 in x 2.8 in x 1.9 in)
Accuracy (Moisture)	±1% WME (Wood Moisture Equivalent)
