Protimeter Surveymaster User Manual

Protimeter Surveymaster Page 7
Reference Mode of Measurement:
Note: For application information, see the section “Using the
Pin (WME) Mode.”
In either mode, take the first measurement which needs to be
taken as reference. While the first reading is displayed on the
screen, press and hold the button for 2 seconds to enter the
Reference Mode. The display will be similar to the one shown
on the next page.
To return to the normal measurement mode, press again.
Settings:
Press and hold the button and switch on the unit by
pressing . Hold both the buttons until the Surveymaster
displays the version.
Release both buttons while it shows the version number. The
unit enters Settings Mode.

Protimeter Surveymaster Specifications

General

Display	Digital LCD
Power Supply	9V Battery
Operating Temperature Range	0°C to 50°C (32°F to 122°F)
Measurement Principle	Electrical Resistance, Radio Frequency
Non-Invasive Measurement Depth	Up to 19mm (3/4 inch)
Dimensions	190 mm x 70 mm x 49 mm (7.5 in x 2.8 in x 1.9 in)
Accuracy (Moisture)	±1% WME (Wood Moisture Equivalent)
