When servicing your marker:
• Make sure your hopper is removed from the marker.
• Make sure there are no paintballs in the breech of the marker.
• Always remove the air supply and relieve all gas pressure in the marker
before disassembly.
• When using the marker in temperatures below 50° Fahrenheit it may be
necessary to lube the REFLEX RAIL™ bolt more frequently.
REFLEX RAIL™ BOLT
ASSEMBLY AND MAINTENANCE
inside the supply
chamber causes the
bolt to start moving
forward. Once the
bolt has moved about
half way forward, the
tail of the bolt closes
the input into the
supply chamber. Once
the Bolt reaches the
forward point, the
valve of the REFLEX
RAIL™ Bolt is opened
and air inside the
supply chamber goes
through the Bolt and
fi res the paintball.
After this the solenoid is deactivated and gas is supplied through the solenoid back into the Can.
This causes the Bolt to return to the back position and the supply chamber to be re-charged.
