TROUBLE SHOOTING GUIDE
W W W . P R O T O P A I N T B A L L . C O M
leak is coming from this hole, remove screw
and apply thread sealant to it.
Make sure to tighten the screw well and wait
for sealant to dry before re-gassing marker.
AIR LEAKING FROM FRONT OF THE REFLEX RAIL™
• Remove the Bolt kit from the marker and
change the #017 O-ring located inside
of the Can and the #014 O-ring located inside
the Manifold. Lube well and re-assemble.
• If above doesn’t help, try changing the #020
O-rings located outside of the Can.
Lube well before re-inserting bolt kit.
PROBLEMS WITH ELECTRONICS
REFLEX RAIL™ WON’T TURN ON
• Make sure battery is new and well charged.
• Check that battery terminals are touching the
contacts on the REFLEX RAIL™ Circuit board
• Make sure there is no dirt or debris blocking
the button from being pressed.
REFLEX RAIL™ WILL TURN ON / OFF BY ITSELF
OR THE EYES WILL TURN ON / OFF BY THEM
SELVES
• Both of these problems are caused because
the button(s) are being held down, as if they
are pressed all the time.
• Remove board from the frame by removing the
grip panel on the left hand side, disconnecting
the cables and removing the board. Carefully
remove the two buttons and clean them well.
• Re-assemble and test. If problems persist,
contact authorized service center.
EYES WILL NOT WORK, LED KEEPS
BLINKING GREEN
• Check that the eye wire is properly connected
to the board.
• Change the battery. The eyes are normally
the fi rst thing to stop working when a battery
is dying.
• Next try to clean the eyes. See page 22 for
details on how to remove the Eye Pipe and
clean the eyes.
To test if the eyes work make sure there
is nothing inside the breech and that the bolt is
in the back position. Turn on the RAIL™, the
light should be red after the boot up sequence.
If it is, the eyes are working.
SOLENOID WILL NOT ACTIVATE / TRIGGER
NOT WORKING
• Check that the trigger is able to press the
microswitch. You should hear a small click
when pulling the trigger.
• If the REFLEX RAIL™ fi res once when turned on
but not after that your trigger is set so that the
micro switch is always activated.
Re-adjust the trigger.
• Change the battery if you are not positive
about it’s charge.
• Check that the solenoid cable is attached to
the board and to the right connector.
26
