Page 25 of 69
Proton Products InteliSENS DG2030 Diameter Gauge Instruction Manual (Issue 1a)
Home page 5
- Gauge status - PID status
- Running average diameter
-Running maximum diameter
- Running minimum diameter
- Line speed (from one of the speed sources: user preset line
speed; measured line speed from the speed pulse input;
measured line speed from analogue input.)
- Calculated cumulative length of object
Press the button to reset length to zero.
Press the button to access the function menu page.
Press the button to return to “Home Page 1”.
