PRO-VISION® Video Systems
28 provisionusa.com
7. Connect the camera connector to the cable running to the DVR unit, if it is not yet installed, install
the cable at this time and then continue to step 8.
8. Hold the camera ball onto the base feeding any excess cable back through the hole in the base.
9. Place the mounting rings of the camera over the ball in the same order as removed, ensure that
the three (3) mounting screws align with the holes in the base.
10. Using a Phillips screwdriver, tighten each of the three (3) screws; leave the screws slightly loose
to allow the camera ball to freely move until the final camera aim is completed.
11. Follow the instructions in Viewing Cameras on a Smart Device to access the unit and aim the
camera. Then tighten the three (3) screws firmly to secure the cameras position.
Example view of the interior of a handicap shuttle bus
