PS Engineering
PMA7000B Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-780-0004 Appendix G Feb. 2004
Cross reference for Bendix/King KMA26
KMA26 PMA7000B KMA26 PMA7000B
P261 Bottom Top
Function
P262 Bottom Top
Function
1 20 Aircraft Power 1 N/C Reserved
2 Z Power Ground 2 16 Music 1 L Hi
3 F 28 V Lighting 3 15 Music 1 R Hi
4 9 Com 1 Audio Hi 4 Y Pilot Mic Key
5 10 Com 2 Audio Hi 5 9 Copilot Mic Key
6 J Com 3 Audio Hi 6 8 Pilot Mic Audio Hi
7 12 Nav 1 Audio Hi 7 8 Copilot Mic Audio Hi
8 13 Nav 2 Audio Hi 8 N/C Key ICS Enable
9 S ADF Audio Hi 9 3 Pilot Phone Audio Hi (R)
10 6 DME Audio Hi 10 3 Copilot Phone Audio Hi (R)
11 11 AUX Audio Hi 11 N/C ICS Tie Hi
12 N/C Muted Audio 1 Hi 12 W Cabin Spr Hi
13 N/C Muted Audio 2 Hi 13 N/C PA SPR Hi
14 T Unmuted Audio 1 Hi 14 5 Outer MKR Lamp Out
15 17 Unmuted Audio 2 Hi 15 4 Middle MKR Lamp out
16 U Unmuted Audio 3 Hi 16 A MKR ANT Shield
17 N/C Spare 17 B MKR ANT Center
18 N/C Key Disable 18 R Music 2 Lo
19 N/C Spare 19 T Music 1 Lo
20 N/C Spare 20 N/C Pilot ICS PTT
21 1 Com 1 Audio Lo 21 N/C Copilot ICS PTT
22 1 Com 2 Audio Lo 22 4 Pass 1 Mic Aud Hi
23 1 Com 3 Audio Lo 23 5 Pass 2 Mic Aud Hi
24 1 Nav 1 Audio Lo 24 N/C Reserved
25 1 Nav 2 Audio Lo 25 11 Pass 1 Phones R Hi
26 1 ADF Audio Lo 26 11 Pass 2 Phones R Hi
27 1 DME Audio Lo 27 N/C ICS Tie Lo
28 1 AUX Audio Lo 28 18 PA Mute
29 N/C Muted Audio 1 Lo 29 22 Speaker Audio Lo
30 N/C Muted Audio 2 Lo 30 N/C PA SPR Lo
31 1 Unmuted Audio 1 Lo 31 C Inner MKR Lamp Out
32 1 Unmuted Audio 2 Lo 32 2 MM Sense out
33 1 Unmuted Audio 3 Lo 33 N/C Reserved
34 1 Chassis Ground 34 14 Music 2 Left Hi
