About the PT2000 and TopGun
10 PT2000™ & TopGun™
For complete information about the TopGun module, refer to
Appendix C on page 99.
Figure 2-1: The TopGun Module
The Keypad
The keypads on the PT2000 and TopGun have three types of keys: data
keys, function keys, and action keys (refer to
Figure 2-2 on page 11). Each
key produces a beep when pressed.
