PSI FluorPen FP 100 User Manual

3
1. Technical Specification
Measured and Calculated Parameters:
Fo, Ft, Fm, Fm‘, QY, NPQ 1*, NPQ 2*, OJIP*, LC 1*, LC 2*, PAR**
Cosine Correction**:
Cosine corrected up to 80º angle of incidence
Linearity**:
Maximum deviation of 1 % up to per 10,000 µmol s
-1
m
-
²
Saturating Light:
Adjustable from 0 to 3,000 µmol(photons)/m².s (0 to 100 %)
Actinic Light:
Adjustable from 0 to 1,000 µmol(photons)/m².s (0 to 100 %)
Measuring Light:
Adjustable from 0 to 3,000 µmol(photons)/m².s (0 to 100 %)
Detector Wavelength Range:
PIN photodiode with 697 to 750 nm bandpass filters
Communication:
Bluetooth, USB, or serial (not included in the FluorPen FP 100)
FluorPen 1.0 Software:
Windows 2000, XP, or higher compatible***
Memory Capacity:
Up to 4 Mb
Internal Data Logging:
Up to 100,000 data points
Display:
2 x 8 characters LC display
Keypad:
Sealed, 2-key tactile response
Keypad Escape Time:
Turns off after 3 minutes of no use
Power Supply:
4 AAA alkaline batteries (single use or rechargeable)
Battery Life:
48 hours typical with full operation
Low Battery Detection:
Low battery indication displayed
Size:
120 mm x 57 mm x 30 mm
4.7" x 2.2" x 1.2"
Weight:
180 g, 6.5 oz
Sample Holder:
Mechanical leaf clip (non-destructive for plants, effective for sample pre-darkening)
Operating Conditions:
Temperature: 0 to 55 ºC; 32 to 130 ºF Relative humidity: 0 to 95 % (non-condensing)
Storage Conditions:
Temperature: -10 to +60 ºC; 14 to 140 ºF Relative humidity: 0 to 95 % (non-condensing)
Warranty:
1 year parts and labor (see the last page of this Operation Manual for precise conditions)
