PT200MI instruction manual 26
Step 4: LOW LOW set-point setting (LL)
Transmit Response
[num]<CR><LF> S-LL [num]<CR><LF>
Options for [num]
The value of the required comparison weight.
N<CR><LF> to move to the next setting.
R<CR><LF> to return to normal weighing.
HH-S [NUM]<CF><LF>
YES
Step 5: HIGH HIGH hysteresis set-point setting (HH-S)
Transmit Response
[num]<CR><LF> HH-S [num]<CR><LF>
Options for [num]
The value of the required comparison weight.
N<CR><LF> to move to the next setting.
R<CR><LF> to return to normal weighing.
HI-S [NUM]<CF><LF>
YES
Step 6: HIGH hysteresis set-point setting (HI-S)
Transmit Response
[num]<CR><LF> HI-S [num]<CR><LF>
Options for [num]
The value of the required comparison weight.
N<CR><LF> to move to the next setting.
R<CR><LF> to return to normal weighing.
LO-S [NUM]<CF><LF>
YES
Step 7: LOW hysteresis set-point setting (LO-S)
Transmit Response
[num]<CR><LF> LO-S [num]<CR><LF>
Options for [num]
The value of the required comparison weight.
N<CR><LF> to move to the next setting.
R<CR><LF> to return to normal weighing.
LL-S [NUM]<CF><LF>
YES
Step 8: HIGH HIGH hysteresis set-point setting (LL-S)
Transmit Response
[num]<CR><LF> LL-S [num]<CR><LF>
Options for [num]
The value of the required comparison weight.
N<CR><LF> to move to the next setting.
R<CR><LF> to return to normal weighing.
S-HH [NUM]<CF><LF>
YES
An error will occurs if the following setting condition is not satisfied: HH HI LO LL,≧ ≧ ≧
transmit N<CR><LF> to restart from steps 1 to step 8.
If one of the set-point values is zero then that comparison will not be performed.
