PT200MI instruction manual 38
10.9 PT200MI FUNCTION LIST
Function
Customer’s files
No. Description Default
F0 (0) Exit setting F0 = 0
F1 (0 – 1) Zero track time F1 = 0 No track
F2 (0 – 2) Zero track band F2 = 1 2 step width
F3 (0 – 3) Motion detection F3 = 1 3 step width/sec
F4 (0 – 5) Multiplier or decimal point F4 = 1 Decimal point
F5 (0 – 2) Division F5 = 0 1 step width
F6 (0 – 21) Max. capacity F6 = 11 10000
F7 (0 – 3) Baud rate F7 = 2 9600 baud rate
F8 (0 – 1) RS232/RS485 output mode F8 = 1 Command mode
F9 (0 – 1) Unit F9 = 0 kg
F10 (0 – 9) Zero return range F10 = 3 4%
F11 (0 – 9) Digital filter F11 = 0 0
F12 (0 – 4) Display update rate F12 = 4 20 times/sec
F13 (0 – 7) BCD output rate F13 = 6 100 times/sec
F14 (00 – 99) RS485 ID code F14 = 01 01
F15 (0 – 6) Peak hold F15 = 0 No peak hold
F16 (0 – 8) Input 1 F16 = 0 Function
F17 (0 – 8) Input 2 F17 = 1 Zero return
F18 (0 – 8) Input 3 F18 = 2 Tare
F19 (0 – 2) Comparison condition F19 = 0 Gross weight
Note: Due to continuous product improvements product changes may occur without notification.
Refer to our web site at www.ptglobal.com for the latest information and revisions.
