Operation
Input/Output Descriptions
Relay Outputs
The APEX Access Device is equipped with two Form C relays:
Relay 1 is used to trigger an access point (door strike, gate
operator, etc.).
Relay 2 can be used for several different functions depending on
the options set.
Relay 2 can be set for
See the APEX Access Device
Setup Function section for
instructions on changing the
settings
SLAVE TO RELAY 1
DIFFERENT HOLD TIME
AUX. OUTPUT
HOLD OPEN BY TIME
ALARM OUTPUT.
•
Slave to Relay 1.
With this function, Relay 2 will operate simultaneously with Relay 1.
• Some installations may use a secondary slide gate as well as a barrier
gate.
• In these applications, Relay 2 can be used to trigger the secondary gate at
the same time as the primary gate and eliminate the need for an isolation
relay
APEX Access Device
25
rev. 7-2017 114A3863.E
