Technical Specifications
Input Power:
Voltage: 12 – 18 VAC or DC
Current Consumption: 300mA Maximum
Relay Specifications:
Maximum Switching Voltage: 30 VAC / 30VDC
Maximum Switching Current: AC: 10A (NO) / 3A (NC)
DC: 5A (NO) / 3 A (NC)
* Resistive load
Environmental:
Ambient Temperature: -40°C to +85°C
(-40°F to 185°F)
Ambient Humidity: 0 to 85% non-condensing
APEX Access Device
1
rev. 7-2017 114A3863.E
