When Relay #2 is set for:
AUX. OUTPUT
Causes Relay 2 to operate as a separate
relay for door or gate access, lighting zones,
elevators, etc. It is independent of Relay #1
and controlled by the controller. This feature
allows the APEX to be used as a 2-channel
relay as well as an access device.
When Relay #2 is set for:
ALARM OUTPUT
Activates Relay 2 when a system alarm
occurs, allowing the relay to be used to
control an external siren horn or other alarm
device.
When Relay #2 is set for:
HOLD OPEN BY TIME
Allows Relay 2 to be used for a secondary
slide gate or other overlock device that will
be held open at a fixed time of day. You
can set the open and close times for each
weekday and for holidays. The next holiday
date is also programmed.
Enter MONDAY
OPEN Time
PRESS # WHEN DONE
Sets the time of day on Monday that Relay
2 will activate
Enter MONDAY
CLOSE Time
PRESS # WHEN DONE
Sets the time of day on Monday that Relay
2 will deactivate
Enter TUESDAY
OPEN Time
PRESS # WHEN DONE
Sets the time of day on Tuesday that Relay
2 will activate.
Enter TUESDAY
CLOSE Time
PRESS # WHEN DONE
Sets the time of day on Tuesday that Relay
2 will deactivate.
Enter WEDNESDAY
OPEN Time
PRESS # WHEN DONE
Sets the time of day on Wednesday that
Relay 2 will activate.
Enter WEDNESDAY
CLOSE Time
PRESS # WHEN DONE
Sets the time of day on Wednesday that
Relay 2 will deactivate.
APEX Access Device
36
114A3863.E rev. 7-2017
