Puls PD-20S - Technical Specifications

42
b. Technical Specificaons
GENERAL
Power Supply 18---32 VDC
Inputs 1 Unit Digital
1 Unit Analog (Load Cell)
Outputs 16 Bit Analog Output (0-10V, 4-20mA , 0-20mA)
Modbus RTU (RS485)
Transistor Output (500 mA)
Protecon Class IP 54
DISPLAY
Display 7 mm 7 Segment DISPLAY
Display Step x1 , x2 , x5, x10, x20, x50
Decimal Display 0.1, 0.01, 0.001
Keypad 4 Units Membrane Type
A/D CONVERTOR
Type 24 bit Delta-Sigma ADC
Converng Speed 100 HZ
Display Precision 1/100.000
FILTER AND CALIBRATION
Digital Signal Filter It is internal filter of ADC.
An-vibraon Filter Special Filter for Vibrated Environments
Parametric Calibraon Done while being connected to the Load Cell
Weighted Calibraon With standard weights.
LOAD CELL
Power Supply 10 V DC
Number of Load Cells 4 Units 350 Ω or 8 Units 700 Ω
Input Resistance Min. 85 Ω
Output Signal at Max Load ≤ 4 mV/V
Connecon Connecon with 4 or 6-core cable.
COMM. INTERFACE
Serial Port-Modbus RTU RS 485
Serial Port-Free Protocol RS 232 to RS 485 convertor with RS 232 output possibility.
AMBIENT AND EQUIPMENT
Operang Temperature -10 °C ~ +40 °C
Humidity %85
Box Rail Mounng Special Plasc Box
