Puls PD-20S User Manual

45
a. Load Cell Connecon
( - ) Excitaon
( - ) Signal
( + ) Excitaon
( + ) Signal
5
5
6
7
8
6
7
8
- EXC.
+SGN.
- SGN.
+ E X C.
5
6 7 8
PULSE ELECTRONIC LOAD CELL CONNECTION
(It can be different for other brand’s Load Cells)
( - ) Exc
Black
Red
Green
White
( - ) Sig
( + ) Exc
( + ) Sig
