Puls PD-20S - External Input-Output Connections; Power Connection

46
b. External Input-Output Connecons
c. Power Connecon
Reseng or Start Input
Analogue Com. (-) Output
Analogue Current Output (+) (0-20mA, 4-20mA)
Analogue Voltage Output (+) (0-10 V)
(TR-1 ) Transistor Output-1 (500 mA)
(TR-2) Transistor Output-2 (500 mA)
RS485 (A),(+) Signal
RS485 (B),(-) Signal
Grounding
(+) 24V Supply
Modbus Grounding (COM)*
(-) 24V Supply
1
2
3
4
9
10
11
12
13
14
15
16
*It is communicaon grounding. Thanks to this external ground wiring,
secure connecon is ensured between the transmier and devices
connected to it. Accordingly, device burnings which are frequently
encountered in the industrial applicaons can be avoided.
