Page 19 of 52
Figure 21
6.3 Drive Motor Wiring
Wire the PulsaPro drive motor according to the motor vendor’s nameplates and instructions, and
according to any appropriate national and local electrical codes and regulations.
6.4 Motor Rotation
Verification of the motor direction is necessary at startup. The motor direction must be counterclockwise
as indicated on the gearbox by a directional arrow.
Figure 22
