For Models with Metal Heads and Metal Diaphragms:
REAGENT HEAD BOLTS
TIE BAR BOLTS
Reagent head Bolts
# Bolts and Thread
size
Torque (2)
# Bolts and Thread
size
Torque (2)
FT-LBS
N-M
IN-LBS
N-M
MW160076 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160022 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160074 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160055 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160018 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160023 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160019 (8) 5/16-18 2 3 (4) 1/4-20 12.0 1.3
MW160024 (8) 5/16-18 2 3 (4) 1/4-20 12.0 1.3
MW160020 (8) 7/16-14 9.0 12 (4) 5/16-18 15 1.7
MW160025 (8) 7/16-14 10 14 (4) 5/16-18 15 1.7
MW160021 (6) 1/2-13 15.0 20 (4) 1/2-13 30 3.4
MW160026 (6) 1/2-13 15.0 20 (4) 1/2-13 30 3.4
MW160056 (6) 1/2-13 15.0 20 (4) 3/8-16 18 2
MW160058 (6) 1/2-13 15.0 20 (4) 3/8-16 18 2
MW160064 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160065 (8) 5/16-18 2 3 (4) 1/4-20 12.0 1.3
MW160067 (8) 7/16-14 9.0 12 (4) 5/16-18 15 1.7
MW160070 (4) 3/8-16 3 4 (4) 1/4-20 12.0 1.3
MW160071 (8) 5/16-18 2 3 (4) 1/4-20 12.0 1.3
MW160072 (8) 7/16-14 9.0 12 (4) 5/16-18 15 1.7
For Models with PTFE/PVC Heads and PTFE Diaphragm:
REAGENT HEAD BOLTS
TIE BAR BOLTS
Reagent Head#
# Bolts and
Thread Size
Torque
(2)
# Bolts and
Thread Size
Torque
(2)
FT-LBS
N-M
IN-LBS
N-M
W204374
(8) 5/16-18
1.5
2.0
(2) 1/4-20
3.0
0.3
W203668 (4) 3/8-16 5.9 8.0 (2) 3/8-16 9.3 1.1
W204785 (6) 1/2-13 10.2 13.8 (2) 1/2-13 21.0 2.4
W209925 (6) 1/2-13 8.8 11.9 (2) 3/8-16 17.8 2.0
W204008 (6) 3/4-10 29.9 40.5 (2) 5/8-11 68.0 7.7
W204829
(6) 3/4-10
47.7
64.7
(2) 1/2-13
90.6
10.2
