Signal definition table
Signal
XDIR- Negative at the horizontal axis
YDIR- Negative at the vertical axis
5VG 5V Power Ground
XCP- Negative pulse at the horizontal axis
ZDIR- Negative at the perpendicular axis
ZCP- Negative pulse at the perpendicular axis
YCP- Negative pulse at the vertical axis
XDIR+ Positive at the horizontal axis
XCP+ Positive pulse at the horizontal axis
ZDIR+ Positive at the perpendicular axis
YCP+ Positive pulse at the vertical axis
YDIR+ Positive at the vertical axis
+5V +5V/500mA Power output
ZCP+ Positive pulse at the perpendicular axis
1
Number of
the 15 pin
interface
2
6
4
3
7
5
9
11
15, 8
10
14
13
12
Remarks
