GROUNDING INSTRUCTIONS
The ground terminal on the frame can be used to connect the
generator to a suitable ground source. The ground path should be
made with #8 size wire. Connect the grounding wire securely to the
ground terminal. Connect the other end of the wire securely to a
suitable ground source.
A metal underground water pipe in direct contact with the earth
for at least 10 feet can be used as a grounding source. If a pipe is
unavailable, an 8 foot length of pipe or rod may be used as the ground
source. The pipe should be 3/4” diameter or larger and the outer
surface must be noncorrosive. If a steel or iron rod is used it should
be at least 5/8” diameter and if a nonferrous rod is used it should be at
least 1/2” diameter and be listed as material for grounding. Drive the
rod or pipe to a depth of 8’. If a rock bottom is encountered less than
4 feet down, bury the rod or pipe in a trench. All electrical tools and
appliances operated from this generator, must be properly grounded
by use of a third wire or be “Double Insulated”.
It is recommended to:
1. Use electrical devices with 3 prong power cords.
2. Use an extension cord with a 3 hole receptacle and a 3 prong plug
at the opposite ends to ensure continuity of the ground protection
from the generator to appliance.
We strongly recommend that all applicable regulations relating to
grounding specications be checked and followed.
DANGER
Improper connection of the equipment grounding
conductor can result in a risk of electrocution.
Check with a qualied electrician if you are in doubt as to whether
the unit is properly grounded for your local regulations.
